MQTT IO Modules
MQTT IO Modules MQTT IO Modules MQTT IO Modules MQTT IO Modules MQTT IO Modules

MQTT IO Modules

30000 INR/Unit

Product Details:

  • Product Type MQTT Converter
  • Number of Channels 8/16 Channel - DI/DO
  • Call Control Protocol MQTT
  • Storage Temperature -25 ~ +75 C Celsius (oC)
  • Network Connection Methods Wireless
  • Power 3.92.9 W Max. Watt (w)
  • Dimension (L*W*H) 97 x 120 x 42 (W x L x H) Millimeter (mm)
  • Click to View more
X

MQTT IO Modules Price And Quantity

  • 1 Unit
  • 30000.00 - 40000.00 INR/Unit
  • 30000 INR/Unit

MQTT IO Modules Product Specifications

  • 8/16 Channel - DI/DO
  • 8/16 Channel - DI/DO
  • Industrial
  • 3.92.9 W Max. Watt (w)
  • +12 ~ +48 VDC
  • MQTT
  • 97 x 120 x 42 (W x L x H) Millimeter (mm)
  • Black
  • -25 ~ +75 C Celsius (oC)
  • Wireless
  • Metal
  • Required
  • MQTT Converter

MQTT IO Modules Trade Information

  • Cheque
  • 1000 Unit Per Month
  • 4 Days
  • Contact us for information regarding our sample policy
  • Device
  • All India
  • CE, FCC, ROHS

Product Description

The MQ-72XX are Ethernet I/O devices equipped with 8/16 - channel DI and 8- channel DO, as well as the MQTT protocol is supported for connecting with a variety of digital sensors in Industrial Internet of Things (IIoT) applications.

A web-based user interface is provided to configure module, monitor the network connection status and I/O status, and control DO lines on the module via a normal web browser on a mobile device or computer.

The MQ-72XX feature optical isolation for 2500 VDC of transient overvoltage protection but do not provide channel-to-channel isolation.

Each output channel can drive up to 650 mA load, together with configurable power-on value and safe value. The MQ-7200M module can safely be used in applications where hazardous voltages are present.


Key Feature: -

  1. Built-in Web Server
  2. Web HMI
  3. Support for MQTT Protocol
  4. 2-port Ethernet Switch for Daisy-Chain Topology
  5. Dual Watchdo
  6. Wide Operating Temperature Range: -25ï +75C
  7. Built-in I/O
  8. DI: 8 / 16 Channels
  9. DO: 8 Channels

ï


Applications: -

Building Automation, Fire alarm system, Smart Factory, etc.


Ordering Information: -

Model Description
MQ-7244M MQTT I/O Module with 2-Port Ethernet Switch, with 8-ch DI and 8-ch DO
MQ-7251M MQTT I/O Module with 2-Port Ethernet Switch, with 16-ch DI
MQ-7252M MQTT I/O Module with 2-Port Ethernet Switch, with 8-ch DI and 8-ch DO
MQ-7253M MQTT I/O Module with 2-Port Ethernet Switch, with 16-ch DI
MQ-7255M MQTT I/O Module with 2-Port Ethernet Switch, with 8-ch DI and 8-ch DO
