Multifunction Power Analyzer

Product Description

Description

CPM-90 multifunction power analyzer provides high-accuracy measurement and is designed for single phase and three phase application. It includes 4 Digital inputs, 4 Relay outputs, and a RS-485 Modbus RTU Communication port. The user can choose one more communication port, and 2 Analog outputs for output expansion.

It provides measure voltage and current of the 263 harmonic, and it shows CO2 emissions, which is suitable for power monitoring, management and analyze power quality. It has TOU (time-of-use) function and 4MB Flash memory capacity, allowing users to record data for a long time. It also has a software line adjustment function to reduce the on-site line adjustment work.

It has the functions of waveform capture and recording, power record, and event record, which can be used for multifunction power analyzer.

Features

– High Accuracy: 0.2S

– Ethernet communication (Modbus TCP/IP)

– Swell/ Sag

– Waveform Capture

– TFT LCD Full color screen

– Sampling rate up to 512 point/cycle

– Power quality Class A IEC61000-4-30

– Plug and play IO module and reverse OEM function for each different application.

– Graphical and Dialogue user interface.

– Customize language menu for each different country.

– Touch Screen operation.

Applications

– Voltage swell and sag detection record

– Power abnormal event record

– Waveform capture and recording

– Analysis of energy quality

Accuracy & Resolution
