BACnet I/O module

Product Description

FeaturesRead/Write 4AI, 2AO, 4BI, 4BO via BACnet/IPAct as BACnet/IP ServerSupport Web-based configurationSupport to Import/Export configuration fileHigh reliability in harsh environmentsDIN-Rail mountableIntroductionBACnet (Building Automation and Control Network) is a communication protocol specifically designed for building automation and control systems. It was established by the American Society of Heating, Refrigerating, and Air-Conditioning Engineers (ASHRAE) in 1995 and has been adopted by the International Organization for Standardization (ISO) as a standard (ISO 16484-5). BACnet aims to enable interoperability between devices from different manufacturers, particularly those involved in Building Management Systems (BMS), such as HVAC, lighting control, security systems, fire alarms, and more. BACnet supports various transmission media, including IP networks, RS-485, ARCNET, and MS/TP (Master-Slave/Token Passing), making it adaptable to different installation environments. Its ability to integrate and manage multiple devices in automation systems has made it one of the most widely used communication protocols in modern smart buildings.The BNET-2310M is a multifunctional BACnet/IP IO module, featuring 4 AI channels, 2 AO channels, 4 DI channels, and 4 DO channels. The module contains multiple BACnet objects, including Device, AI, AO, BI, and BO, and supports various BIBBS (such as DS-RP-B, DS-RPM-B, DS-WP-B, DS-WPM, DS-COV-B, etc.). The module has a built-in web server, allowing users to easily and securely configure the module remotely via a web interface.CPU ModuleWatchdog TimerYesSystemSecurityID and PasswordLED IndicatorsStatusPower, Ethernet and BIP statusAnalog InputChannels4 Single-endedRange1 V, 2.5 V, 5 V, 10 VResolution16-bitAccuracy0.1%Sampling Rate10Hz(Total channels)Overvoltage Protection+120 VDCIndividual Channel ConfigurationYesAnalog OutputChannels2Range0 V +5 V, 5 V, 0 V +10 V, 10 VResolution12-bitAccuracy0.1%Individual Channel ConfigurationYesDigital InputChannels4TypeDry ContactSink/Source (NPN/PNP)Source(PNP)ON Voltage LevelClose to GNDOFF Voltage LevelOpenOvervoltage Protection+60 VDCDigital OutputChannels4TypeOpen CollectorSink/Source (NPN/PNP)Source(PNP)Load Voltage+10 VDC +40 VDCLoad Current650 mA/channelOvervoltage Protection47 VDCOverload ProtectionYesEthernetPorts1 x RJ-45, 10/100 Base-TXBACnet/IPProtocolBACnet/IP ServerObjects1 Device, 4 AI, 2 AO, 4 BI, 4 BOBIBBsDS-RP-B, DS-RPM-B, DS-WP-B, DS-WPM-B, DS-COV-B, DM-DDB-B, DM-DOB-B, DM-DCC-B, DM-TS-B, DM-UTC-B, DM-RD-BPowerInput Range+10VDC to +30VDCConsumption3.6W (0.15A @24VDC)MechanicalCasingMetalDimensions (mm)33 x 120 x 106 (W x L x D)InstallationDIN-Rail MountingEnvironmentOperating Temperature-25 +75 CStorage Temperature-30 +85 CHumidity10 90% RH, Non-condensing
