BACnet/IP to Modbus TCP Gateway

BACnet/IP to Modbus TCP Gateway

Product Details:

  • Product Type BACnet
  • Storage Temperature -30 ~ +80 Celsius (oC)
  • Network Connection Methods Wired
  • Power 5W @ 24VDC Watt (w)
  • Dimension (L*W*H) 33 x 120 x 116 Millimeter (mm)
  • Weight 200 Grams (g)
  • Power Supply 24VDC
  • Click to View more
X

BACnet/IP to Modbus TCP Gateway Price And Quantity

  • 10 Piece

BACnet/IP to Modbus TCP Gateway Product Specifications

  • Black
  • -30 ~ +80 Celsius (oC)
  • 200 Grams (g)
  • 5W @ 24VDC Watt (w)
  • 33 x 120 x 116 Millimeter (mm)
  • +10 VDC ~ +30 VDC
  • Industrial
  • Plastic
  • BACnet
  • 24VDC
  • Wired

BACnet/IP to Modbus TCP Gateway Trade Information

  • Cheque
  • 1000 Piece Per Month
  • 4 Days
  • Device
  • Asia Australia Central America North America South America Eastern Europe Western Europe Middle East Africa
  • All India
  • CE/FCC/ROHS

Product Description

Features

  • Read/Write Modbus registers via BACnet objects
  • Configurable BACnet/IP Server
  • Configurable Modbus TCP Client
  • Supports BACnet AI, AO, AV, BI, BO, BV, MSI, MSO, MSV Object Types
  • Supports Modbus discrete inputs, coils, input registers and holding registers
  • Supports up to 180 DI, 180 DO, 180 AI and 180 AO to transfer to BACnet Objects
  • Simple data translation allows you to manipulate data as it passes between protocol

Introduction

GW-2493M is a network gateway allowing BACnet client devices to be accessed Modbus network as a Modbus TCP client. The BACnet/IP protocol is used to relay and exchange information between building devices. GW-2493M contains a large number of BACnet objects (AI, AO, AV, BI, BO, BV, MSI, MSO, MSV) gives you flexibility in mapping Modbus TCP registers to any combination of BACnet objects. Multiple BIBBs (DS-RP-B, DS-RPM-B, DS-WP-B, DS-WPM-B,etc.) are supported. All the data transfer is configurable using a standard Web browser.

LED Indicators
Status Power (1), BACnet/IP Status (1), BACnet/IP Net(1),
Modbus TCP TxD/RxD/Link (3)
Ethernet LED Ethernet Status (RJ-45) (2)
Ethernet
Ports 1 x RJ-45, 10/100Base-TX
BACnet/IP
Protocol Modbus TCP Client(Supports up to 32 stations)
Objects AI, AO, AV, BI, BO, BV, MSI, MSO, MSV(Convert modbus 180 DI, 180 DO, 180 AI and 180 AO)
BIBBs DS-RP-B, DS-RPM-B, DS-WP-B, DS-WPM-B, DM-DDB-B, DM-DOB-B, DM-DCC-B, DM-RD-B
Power
Input Range +10 +30 VDC
Consumption 5W @ 24VDC
Mechanical
Casing Metal
Dimensions (mm) 33 x 120 x 116
Installation DIN-Rail
Environment
Operating Temperature -25 +75 C
Storage Temperature -30 +80 C
Humidity 10 90% RH, Non-condensing
