16 Ch Digital Output Module

16 Ch Digital Output Module

23600.0 INR/तुकडा

उत्पादन तपशील:

  • उत्पादनाचा प्रकार Digital Module
  • चॅनेलची संख्या 16 Channel
  • स्टोरेज तापमान सेल्सिअस (ओसी)
  • नेटवर्क कनेक्शन पद्धती Wired
  • पॉवर वॅट (प)
  • आकारमान (एल* प* एच) मिलीमीटर (मिमी)
  • वजन ग्रॅम (ग्रॅम)
  • अधिक पाहण्यासाठी क्लिक करा
X

किंमत आणि प्रमाण

  • 1

उत्पादन तपशील

  • Wired
  • Plastic
  • +10 VDC ~ +30 VDC
  • Digital Module
  • 16 Channel
  • 24VDC
  • वॅट (प)
  • Gray
  • सेल्सिअस (ओसी)
  • मिलीमीटर (मिमी)
  • ग्रॅम (ग्रॅम)

व्यापार माहिती

  • प्रति महिना
  • दिवस
  • Device
  • , , , , , , , ,
  • CE/FCC/ROHS

उत्पादन वर्णन

FeaturesSource-type Digital Output with Overload ProtectionConfigurable Power-on Value and Safe Value SettingsShort Circuit ProtectionOverload and Overvoltage ProtectionBuilt-in Dual WatchdogIntroductionThe M-7045 series offers 16 digital output channels, each of which features photocoupler isolation. The M-7045 supports source-type output, while The M-7045-NPN supports sink-type output, and both are equipped with short circuit protection. The M-7045D/M-7045D-NPN provides 16 LED indicators for channel status monitoring.The M-7045(D)/M-7045(D)-NPN supports Modbus RTU and DCON protocols, which can be configured via software. There are also options for configuring power-on and safe values. 4 kV ESD protection, 4 kV EFT protection, 3 kV surge protection for power input, and 3750 VDC Intra-module isolation are standard, and all hardware specifications are the same as the I-7045(D)/I-7045(D)-NPN.Applications Building Automation Factory Automation Machine Automation Remote Maintenance Remote Diagnosis Testing EquipmentCPU ModuleWatchdog TimerModule, Communication (Programmable)DisplayTypeI/O LED IndicatorIsolationIntra-module Isolation3750 VDCEMS ProtectionEFT (IEC 61000-4-4)4 kV for the 16 DO channels and Power,2 kV for the RS-485 PortESD (IEC 61000-4-2)4 kV Contact for Each Terminal8 kV Air for Random PointSurge (IEC 61000-4-5)3 kV for Power LineLED IndicatorsStatus1 x Power and Communication16 x Digital OutputDigital OutputChannels16TypeOpen SourceSink/Source (NPN/PNP)SourceLoad Voltage+10 +40 VDCLoad Current650 mA/ChannelOvervoltage Protection47 VDCOverload Protection1.4 AShort-circuit ProtectionYesPower on ValueProgrammableSafe ValueProgrammableCOM PortsPorts1 x RS-485Baud Rate1200 115200 bpsData Format(N, 8, 1)ProtocolModbus RTU, DCONPowerReverse Polarity ProtectionYesInput Range+10 +30 VDCConsumption1.5 WMechanicalDimensions (mm)72 x 123 x 35 (W x L x H)InstallationDIN-Rail MountingEnvironmentOperating Temperature-25 +75 CStorage Temperature-40 +85 CHumidity10 95% RH, Non-condensing

FAQs of 16 Ch Digital Output Module:


Q: What is the power consumption of the 16 Ch Digital Output Module?

A: The power consumption of the 16 Ch Digital Output Module is 1.5 Watt (W).

Q: How many channels does the module support?

A: The module supports 16 channels.

Q: What is the voltage range supported by this module?

A: The module supports a range of +10 VDC to +30 VDC.

Q: What type of network connection method is supported?

A: The module supports wired network connection methods.

Q: What are the dimensions of the module?

A: The dimensions of the module are 72 x 123 x 35 mm (Width x Length x Height).
